B147K 5LK1500 V-Belt

The B147K also known as 5LK1500 Kevlar V Belt is a long length heavy duty V belt reinforced with aramid fiber cords for maximum strength and zero stretch. Built for extended span belt drives this belt performs under constant load and frequent engagement in agricultural and industrial machinery.

Belt Specifications
Type: B Section Kevlar V Belt
Top Width: 0.66 inches
Depth: 0.4375 inches
Outside Length: 150.0 inches
Effective Length: 147.0 inches

Cross Reference Part Numbers
B147K
5LK1500
Dayco L747K
Gates 69150
Carlisle B147K
Pix B147K
D&D B147K
MBL B147K
Bestorq B147K

Applications
Used in hay equipment conveyors augers and industrial fans requiring long non stretching belts for high load and torque transfer

Key Features
Kevlar cords eliminate elongation and maintain belt stability
Performs in high tension and shock load environments
Built to resist oil heat and wear in continuous operation
